Description
concrete permanent assembly-free form RIB Lath-chiefence
The goverment is encourage the Infrastructure construction now, If we need building a new house or repair a wall, it is good time to start it.
Here is a good products could using on building,
it is Rib lath,
High Ribbed Form work is manufactured from hot-dipped galvanized steel sheets.
Rib lath is the most rigid for all sheet metal laths for its ribs running the whole length of the sheet added additional strength. Rib metal lath is commonly used for soffits and ceilings.
This lath is ideal for machine applied plaster, backed with 2 strips
As concrete permanent assembly-free form work, widely used in tunnels bridges,valve basement systems, sewage systems, subways, retaining walls, nuclear power plants, shipyards, Water pools marine engineering works high rise building projects, non-regular or bending pattern etc.
Name
Rlb lath-Chiefence
Product range
Plasterers accessories
Products sub-range
concrete permanent assembly-free form RIB Lath
Products type
Rib-lath
materails
Steel plate
Or stainless steel
Coating/finish/colors
Mill finish/galvanized/silver
length
1800-2500mm
Width/wing length
600-800mm
Plaster/render/joist depth
10-13mm
Fire rating
Reaction to fire : Class A1
Packing
10 sheet (20 sq.yds) per bundle, 50 bundles per lift.
Feature
1. Steel materials could add strong for building
2. Modeled into curves/arches
3. Easy cutting into request sizes
4. Strength ribs hold mesh off substrate,
step 1
Put the rib lath point towards the structure
step2
every 5 meters provided movement joints horizontally and vertically for cement-based render,
step3
Don't mix using with Gypsum based plasters
step 4
Overlap sheets 50mm along the short edge, and edge ribs nestled. Fixings to the perimeter at 150mm intervals through ribs,
central fixings at max 600mm every 2nd rib
step 5
It is must wire-tied at 150mm centers if the overlaps are un-supported, pattern should be a ranged in a staggered,
